PROLINK 2KVA UPS PRO2000 SFC
Super Fast Charging Line Interactive Series
PROLiNK SFC series is a single-phase input/ single-phase output Line-Interactive UPS system with PROLiNK’s latest Super-Fast Charging technology. This cutting-edge technology is able to recharge the battery back to 90% of its capacity within 2-4 hours, and is ideal for providing stable backup power to home/ small office applications. A wide input voltage range is supported due to the integrated 3-Step AVR which features 2 boosts and 1 buck to regulate output voltage. This prevents under voltage brownouts and over voltage surges. The unit also comes with universal sockets to provide better compatibility with a wider range of devices.
| Weight | 11.5 kg |
|---|
Description
GENERAL
| Capacity | 2000VA |
| Dimension (mm) | 320 x 130 x 182 (D x W x H) |
| Weight (kg) | 10.6 |
INPUT
| Nominal Voltage | 220VAC / 230VAC |
| Voltage Range | 140 – 300 VAC ± 5% |
| Nominal Frequency | 50 or 60Hz (Auto sensing) |
OUTPUT
| Voltage Requlation | ± 10% |
| Frequency | 50 or 60Hz ± 1Hz |
| Transfer Time (typical) | 2 – 6ms |
| Waveform | Simulated Sinewave |
BATTERY
| Number of Battery | 12 V/10 Ah x 2 |
| Recharge Time (typical) | 2-4 hours recover to 90% capacity |
ALARM & INDICATORS
| LED Display | AC Mode – Green Lighting Battery Mode – Yellow Flashing every 10 seconds Overload – Red Flashing every second Fault – Red Lighting |
| Sounding | Battery Mode – Sounding every 10 seconds Low Battery – Sounding every second Overload – Sounding every 0.5 second Battery Replacement Alarm – Sounding every 2 seconds Fault – Continously sounding |
Rear Panel
|
