CABLE OPTICAL 2m ST TO CS

Connector Type Senko CS™ to CS™

Polish Type UPC to UPC
Fiber Mode OS2 9/125μm

Wavelength 1310/1550nm
400G Ethernet Distance 2km with OSFP-400G-2FR4 Glass Fiber Corning Fiber
Insertion Loss ≤0.2dB Return Loss ≥50dB

Fiber Grade G.657.A1 (Compatible with G.652.D)

Minimum Bend Radius 10mm

Attenuation at 1310 nm 0.4 dB/km Attenuation at 1550 nm 0.22 dB/km
Fiber Count Duplex Cable

Diameter 2.0mm
Cable Jacket PVC Polarity A(Tx) to B(Rx)
Operating Temperature -20 to 70°C Storage Temperature -40 to 80°C
