XPRINTER XP-76iiN DOT MATRIX
Description
XPRINTER XP-76iiN DOT MATRIX
Black mark orientation, supports invoice printing function
Support bi-directional printing
Freshness outstanding design, easy to operate
GB18030 simplified Chinese, support traditional Chinese and various international languages
Various interfaces, multiply choices
Printing | |
Printing method | 9-Pin serial impact dot-matrix printing |
Printing width | 63.5mm |
Print Resolution | 84 dpi |
Printing speed | 4.5 line/s Max. |
Interface | Parallel / USB/ USB+Lan |
Print paper | 75.5±0.5mm Φ65mm |
Character size | ANK,Font A: 1.6×3.1mm(9×9 matrix) Font B: 1.2×3.1mm(7×9 matrix)Chinese,traditional Chinese: 2.7×2.7mm(16×16 matrix) |
Column number | Font A – 33 columns /Font B – 40 columns / Chinese, traditional Chinese – 22 columns |
Character | |
Extension character sheet | PC437/Katakana/PC850/PC860/PC863/PC865/WPC1252/PC866/PC852/PC858 |
Software | |
Driver | Windows /Linux /Mac |
Utility | Windows |
SDK | Windows/ Android |
Power | |
Power adaptor | Input:AC 110V/220V, 50~60Hz,
Output: DC 24V/2.5A |
Printer input | DC 24V/2.5A |
Cutter | |
Auto cutter | Partial |
Physical characteristics | |
Gross weight | 1.46 KG |
Dimensions | 230*150*138mm |
Environmental Requirements | |
Work environment | 0~45℃, 10~80% RH |
Storage environment | -10~60℃, 10~90% RH(no condensation) |
Reliability | |
Printer head life | 10 Million Lines |
