| Performance Parameter |
| Light Source |
Laser |
| Type of Light Source |
650nm |
| Resolution(maximum) |
0.102mm / 4mils |
| Print contrast ratio(minimum) |
≥20% |
| Reading Angle |
Pitch: 0-360°; Roll(Tilt): ±60°; Skew (Yaw): ±60° |
| Decoding Capability |
AN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Code39, Code 39 Full ASCII, Interleaved 2 of 5, Matrix 2 of 5, Coda bar, Code128, Code 93, Code 11, cMSI/Plessey, UK/Plessey, UCC/EAN 128, China post, GS1 DataBar, RSS, etc. |
| Reading Indicators |
LED light&Buzzer(adjustable tone and volume) |
| Typical depth of Field |
(The minimum depth of field is determined by the barcode length and scanning angle. It depends on the
print resolution, contrast and ambient light.)
Precision    Depth of Filed
5mil        40mm—105mm
10mil        10mm—250mm
15mil        23mm—380mm
20mil    35mm—490mm
30mil    30mm—650mm |
| Electrical Parameter |
| Current |
Working current(Standard): |
| Input Voltage |
5 VDC (+/- 10%)/500mA |
| Environmental Parameter |
| ESD protection(Air discharge) |
8 kV |
| Working Temperature |
0 to 40 °C |
| Temperature |
Storage/Transport: -40 to 70 °C |
| Humidity(non-condensing) |
5 – 95% |
| Ambient light |
Indoor: 0 to 6,000 lux; Outdoor: 0 to 86,000 lux |
| Interfaces |
RS-232; USB HID; USB COM |
| Safety Level of Laser |
EN60825-1,class 1,National first-class laser safety standard |
| Certificates |
CE, FCC, ROHS, ISO |
| Warranty |
12 month |
